Champion Cooling

1985-1997 Ford Bronco 3-Row LS Swap Radiator - Champion Radiator

1985-1997 Ford Bronco 3-Row LS Swap Radiator - Champion Radiator

Regular price $535.98 USD
Regular price Sale price $535.98 USD
Sale Sold out
Quantity

1985-1997 Ford Bronco 3- ROW Radiator

3-Row Core | Cools up to 750hp

For Chevy LS Conversions


1985-1997 Ford Bronco ls swap radiator dimensions

Radiator Dimensions:

Total: 22.25" tall (with cap) x 37.25" wide
Core: 18" tall x 28.13" wide x 2" thick
Inlet: 1.5" passenger side
Outlet: 1.5" drivers side
Tanks: 3" thick
Tubes: 0.63" thick



Whats Included

- 13lb. Radiator Cap included
- Transmission Cooler Included (1/4-18NPT)

1985-1997 Ford Bronco ls swap 3 core radiator



Add On Options

Fan Upgrades:

SPAL High Performance Series -2044
13" Cooling Fan
Curved Blade - Pull

Specifications:
A: Length 14.17"
B: Depth 3.45"
C: Width 13.62"

CFM: 1777
AMP Draw: 19.5 Amps

2044 1777 cfm fan



Thermostat / Relay Kit:

Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°

POLISHED OVERFLOW TANK:

Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets

48" Polished Stainless Steel Radiator Hose Kit:

4 Polished End Caps
4 sets of rubber inserts (to fit either 1.25", 1.5" or 1.75" radiator outlets)

dual fan relay kit


Core Size

  • 3 Row

Application

Ford /

View full details

Dimensions

Whats Included

Add On Options

Thermostat / Relay Kit:

Our Waterproof Thermostat Relay Kit turns your fans on when the temperature of the engine reaches 185° and off at 170°

STAINLESS OVERFLOW TANK:

Twist-in aluminum cap ,Holds up to 18 fluid ounces, Polished Aluminum, Universal Mounting Brackets
